MAG A750BN PCIE5 provides players with a safe, reliable, and efficient power supply option. Its core features include 16-pin PCIe 5.0 connector, 80 PLUS Bronze certification, DC-to-DC circuit design, active PFC, and low-noise fan. With the A750BN PCIE5, any system has the power it needs to survive all challenges.
The efficiency of your power supply directly influences your system’s performance and your power consumption. The 80 PLUS BRONZE certification promises lower energy consumption and higher efficiency.
Through the native 16-pin PCIe connector, the PSU can provide up to 300W of power to a PCIe 5.0 GPU, enabling to support the RTX 4070* series graphics cards.
*RTX 4070Ti SUPRIM X 12 G is not compatible.
Extra GPU power feeds (8-pin PEG connectors) support a broad array of NVIDIA and AMD graphics cards.
Adopted DC-to-DC circuit design reduces the instability of output voltage, and ads stability to the supply of power.
Supports OCP, OVP, SCP, OPP, OTP protection mechanisms and provides comprehensive protection.
The fan's sleeve bearing reduces the noise generated while maintaining excellent heat dissipation.
Your system can safely operate at maximum load in temperatures up to 40℃.
This power supply unit is made to last, regardless of what environment your system is in.
A compact 140 mm-long and 150 mm-wide ATX form factor ensures a comfortable and easy fit in most PC cases. This frees up more space for cable management and airflow to the rest of the system.
A wide range of connectivity options provides extensive hardware support.
Connect and upgrade multiple hard drives, SSDs, graphics cards and other components quickly and easily.
| Modular | No |
| Fan Bearing | Sleeve Bearing |
| Power Watt | 750W |
| Input Voltage | 100-240~ |
| Input Frequency | 50~60Hz |
| Efficiency | 80 PLUS Bronze (up to 85%) |
| ATX (24 pin) | 1 |
| EPS (4+4 pin) | 2 |
| Fan Size | 120 mm |
| PCI-E 5.0 (16 pin) | 1(300W) |
| Dimension | 140mm x 150mm x 86mm / 5.51 x 5.9 x 3.38 inches |
| PCI-E (6+2 pin) | 2 |
| PFC Type | Active PFC |
| SATA (15 pin) | 5 |
| Protection | OCP, OVP, OPP, OTP, SCP |
| MOLEX (4 pin) | 2 |
| FDD (4 pin) | 1 |
